Features:
- Microcomputer control, brushless motor variable frequency
- Large screen backlight LCD shows
- 10 groups of ACC /DEC rate to choose and memory
- Electronic door lock control,with emergency unlock device
- Stainless steel chamber
- Imbalanced protection, self locking, overspeed protection, speed no signal protection, motor holzer fault protection, high or low power supply voltage protection, over-current protection
Specifications:
| Model |
LC-04W |
| MAX RPM |
4000 RPM |
| Max RCF |
3150xg |
| Timer |
0-99min |
| Max Rotor capacity |
400ml |
| Voltage |
110V 60Hz /220V 50Hz |
| Dimension |
380×470×280 mm |
| Weight |
25kg |
| Description |
Rotor NO. |
Rotor capacity |
Max RPM/RCF |
| Optical Swing Rotor 1 |
S041524 |
15mlx24 |
4000rpm 2860xg |
| Optical Swing Rotor 2 |
S041516 |
15mlx16 |
4000rpm 2860xg |
| Optical Swing Rotor 3 |
S041508 |
15mlx8 |
4000rpm 2610xg |
| Optical Swing Rotor 4 |
S041506 |
15mlx6 |
4000rpm 2540xg |
| Optical Swing Rotor 5 |
S0410004 |
100mlx4 |
4000rpm 3150xg |
| Optical Swing Rotor 6 |
S045008 |
50mlx8 |
4000rpm 2860xg |
| Optical Swing Rotor 7 |
S045004 |
50mlx4 |
4000rpm 2860xg |
| Optical Swing Rotor 8 |
S043006 |
30mlx6 |
4000rpm 2860xg |
| Optical Swing Rotor 9 |
S041024 |
10mlx24 |
4000rpm 2500xg |
| Optical Swing Rotor 10 |
S040806 |
8mlx6 |
4000rpm 2500xg |
| Optical Swing Rotor 11 |
S040712 |
7mlx12 |
4000rpm 2500xg |
|
|
